29

My bike has Spoken, but can I listen?

background: I currently ride 10 miles/week day, 10-30 miles each weekend on a Diamondback mountain bike "oldish" (unknown age/make - freecycle find)... It weighs about 45 pounds unloaded, and I haul 5-25# of "stuff" around on it for most of those miles, sometimes as much as 50 but that's rare. I've had some issues with the rear derailleur that have settled down lately, and the brakes need to be replaced, but none of that has been a show stopper.


Problem: (incorrect vocabulary follows - I apologize) This morning, I was attempting to shift from 2-3 (it's got 3) on the front gear with the rear gear at 5 (it's got 7), I was moving a decent speed, but the chain just got stuck and jammed. I tried again, shifting down to 2 then back to 3, repeated fail. Then I was idiotic (it was 5AM!) and pushed harder on the pedals to force it. Very strange sounds emanated, I shifted back down to 2 on front, and weird as hell sounds continued at 1R with the rear wheel. Pulled in to a parkinglot to diagnose. Rear wheel appears out of true, and a spoke is broken off at the hub. I believe only one is broken. I swore, gently poked at unrelated metal bits while debating how to get to work, then continued via that bike the remaining 6 miles to my car (home was 2 miles away, but no car there, car's at work). Funny, the sounds kind of stopped and it rode like "normal" pretty much immediately. So I have no idea how long this spoke has been broken, or if there was a real problem with the front derailleur (neither initial problem nor horrid sounds happened again). The wheel has not magically trued itself, but no longer rubs the un-actuated rim brake every turn.


In May I had this thing in to Dirty Harry's and said "Please repair/replace *List* that doesn't work, and in general could you give the whole thing a check up and just replace anything that needs it or is about to go, I need a reliable commuting/grocery bike." They said they'd look, but didn't touch beyond my list (via receipt, they may have tinkered but not charged, I don't know). It's been back every two weeks or so since for adjustments of various sorts, mostly derailleur stuff. They're awesome and everything has been free after the initial tune-up, but I'm finding that things are going afoul a little less than a week after I take it in (I give it a few days for the gremlins to leave on their own before I roll down the hill to the shop for the professional exorcism)


Anybody have a more educated guess as to how much of this mess is:

1) it's an old POS bike, or

2) I don't know what I'm doing and somehow breaking it by riding it wrong or not tightening an unknown widget every time I ride.


I asked the guys at DH's, and though they're in the business of fixing broken things AND selling new things, they said it would be fine for what I'm doing. This isn't my definition of fine. Is this normal? The last bike I had I rode only in dirt (there were no roads), never did anything to it for a year and it was fantastic (and then stolen). Is that the difference between OLD and NEW for bikes?


ejwme
2010-07-13 13:08:09

If you're using the regular spiral cable housing for your shifters you should switch to a compressionless housing. I had no end to shifting problems until I went to the compressionless kind. The spiral kind would work nicely for awhile, but then things would start to get crummy.

here's a Sheldon Brown quote :


Although people pay a lot of attention to what kind of derailers and brakes are fitted to a particular bicycle, good cable installation practices are more important than most differences between different brake and shift systems. The most expensive brakes and derailers will work poorly if there is excessive friction or play in their control cables. Even the cheapest brakes and derailers can usually be made to perform satisfactorily if care is used in installing the cables.


The great majority of service problems with brakes and gears are the result of cable friction, not deficiencies in the levers, calipers or derailers.


and here's a link to his page on cables:


Cables


My bike has work wonderfully since I put the compressionless housings on.


boazo
2010-07-13 14:21:42

ooo... that sounds like a try for the derailleur hiccups.


the spoke thing has me spooked, though.


ejwme
2010-07-13 14:28:47

hey, that's the guy with the awesome light advice. I should just bookmark his pages.


Thank you!


ejwme
2010-07-13 14:29:50

yea , he has alot of good info.


boazo
2010-07-13 14:37:53

Bikes have a lot of moving parts and mechanical stresses. Parts break and wear out. They may break more frequently when they weren't high-end to start with.


You can replace the spoke and see if the wheel will get back to true. If there are bigger problems than that with the wheel, you may have to replace it.


If your chain was stuck between two gears and you were jamming on the pedals, you may have bent the chain. You should take a look at that. If one or two links are bent, you could just remove these as a temporary fix, and eventually replace the chain. If it skips after you replace it, you might need a new cassette on the back too.


I don't know if DH replaced your shifter cables, but it sounds like with all your shifting issues maybe the cables themselves have seen better days, or the housings are shot. You can replace both relatively cheaply.


dwillen
2010-07-13 14:52:28

yeah, problems with shifting repeatedly going out of whack does sort of point to cable housing. sometimes new housing will compress a bit over time (even though some people will insist that it's your cables stretching), causing you to frequently adjust things until it finally settles in.


regarding the rear wheel: was it a drive side spoke that broke? that is always more ominous than a front spoke or left side spoke, and of course they seem to go a lot more frequently. if your spokes have ever seen any extra stress or scoring (such as from a chain that has skipped over your biggest sprocket/lowest gear on the rear wheel), you can pretty much bet every one of those spokes will break in the coming months, and a new wheel might be the least expensive way to go.


hiddenvariable
2010-07-13 15:37:34

then again, maybe you should just junk it and get that pink rhinestone bike.


hiddenvariable
2010-07-13 15:38:20

they were new shifter cables, I replaced the shifters prior to taking it in (it was acting like a fixed gear until then). The housings... that's blurry. I don't remember if I pitched the old ones or not (can't check, in different city now)


I'll check the chain... The repair bills are adding up to the cost of a new bike, another $50 and it would have been the same price to purchase the one I'm considering as a gift for the fiance (and am now wondering if that's too cheap - I love the guy and don't want him to go through this!).


I learned on my house that some repairs are "I'll do that myself for mostly nothing and save a bundle" (like adding a 3-way dining room light switch and installing a chandelier) and some repairs are "It will cost twice as much to hire someone to fix my attempt than to just hire someone to do it right to begin with" (like rewiring the rest of the house and breaking up circuits). I'll have to figure out what that is for bikes.


ejwme
2010-07-13 15:40:29

@ejwme --@HV makes a good point above. You want to make sure that the chain did not shift between the large cog in back and the spokes. If you have a broken spoke on the drive side, look very carefully at the other ones to make sure they are not chewed up in any way. If two or three spokes fail at once you are probably going down hard. Such a wheel needs to be fixed/replaced asap.


jeffinpgh
2010-07-13 15:48:21

If you can, get a better quality bike asap. You can always keep the old one for nostalgia rides right?


It's totaly worth every penny in the long run imo


spakbros
2010-07-13 15:53:10

You know to pluck your spokes like a guitar string and listen to the note, right ? see if you get all about the same pitch.


boazo
2010-07-13 15:53:19

You will not regret getting a nicer bike. :) With the amount you're riding (will add up to thousands of miles a year), it's just not worth maintaining such a low end bike. Even fixing that rear wheel is probably going to cost more than the wheel is worth.


johnwheffner
2010-07-13 16:16:27

OOOPs.


I thought I was in another thread and I posted nonsense here.


< NYC cop voice> The show's over. Nothing to look at. < /cop>


mick
2010-07-13 16:19:29

spokes shall be plucked, I'm rather giddy at that test, given my acoustics background. Like I said, my bike has spoken, I just needed to figure out how to listen. If I get any chords I might just sing along.


It was a left side spoke, not drive side, but I'm also not sure if there are other spokes broken or not... I may have two, now that I think about it. I was futzing on the left with the bike right side up at the side of the road, my head in traffic (yes, I know, but that's how I remember). But in the lot it was on the drive side... hmm... further investigations are necessary. Come to think of it, the rear break has been a bit more 1R rhythmic past three days than lately.


What kills me is that the funky noises (spoke breaking?) happened at the same time as the chain jamming, but the two (given the side of the broken spoke) should be unrelated? OR this is truly the beginning of the avalanche of the end of my poor crate bike.


HV, that's funny you talk about the cable housing flattening vs. cable stretching... DH said it was cable stretch. They continue to adjust it very nicely for me when I go in, so maybe it's settled. HA right about when it may be time for a new bike. Am I sick that I honestly think that's funny?


Since the new bike coming in to our household will technically not be mine, I can't bedazzle it (he's secure about himself, but nobody loves me *that* much). Perhaps I could bedazzle removable sleeves for the tubes, so it can convert back to Manly Bike when he uses it on weekends.


ejwme
2010-07-13 16:29:40

Can you knit?



edmonds59
2010-07-13 16:55:58

OH MY GOD.


I can crochet. I can crochet with sparkly pink thread. That is the awesomest thing ever in the whole world. The little blue bird is perfect. The cute little pearl buttons belie excellent attention to detail. Ridiculously fun detail. You have cheered me up immensely :D (and I was pretty cheery to begin with!)


ejwme
2010-07-13 17:14:53

Is this a thread or has it become a yarn? (nyuk, nyuk)


edmonds59
2010-07-13 18:15:37

this thread is giving me the dia-beatis. need insulin now...


:D


cburch
2010-07-13 19:07:15

UPDATE:


Autopsy results are in. One broken spoke, drive side. Spokes on both wheels have high side and low side in pitch when strummed - at least a major third between the extremes (not as much as a perfect fourth). Worse yet, the drive gears 2 and 1 are missing/worn to nubs 5 and 3 teeth respectively. Well, they actually all look pretty worn, but some teeth really didn't have much in the way of even ghosts left. The chain seemed fine.


So I didn't look at the cable housing. Performance didn't have much in stock for me (apparently I describe a niche market), so I'm headed to Dirty Harry's to pick up one of the ones they had shown me before... all I remember is one was a Trek, and one was white, one was red. It was less important at the time!! I'll probably strip it and drop it off at FreeRide this weekend. *sniff* Maybe some kind soul there can ressurect it for its next owner or it can donate its organs to live on through other bikes.


Thank you guys for all your help! I'm actually feeling pretty ok with the decision. Now I just have to worry about whether I can afford what I need, and figure out how to tell the difference.


ejwme
2010-07-14 00:12:20

good luck getting your new ride, that's exciting even though it means moving on from your old bike which you seem to be fond of. take your time deciding! nothing worse than a rushed purchase that you regret.


tabby
2010-07-14 01:46:42

i'm digging the spoke intervals. mine are all tensioned to a diminished chord


noah-mustion
2010-07-14 02:25:20

incidentally, the rear wheel should have spokes on one side tuned to a higher frequency than spokes on the other, but not so in the front.


good luck, and have fun with your quest for a new bike! i suggest shopping around a bit if it's an option. get the one you can afford but can't afford to live without.


hiddenvariable
2010-07-14 03:07:09

way to dish out the advice, there.


noah-mustion
2010-07-14 03:32:36

I like that - can afford, can't afford to live without. I tend to be what appears to be an impulsive buyer - in reality, I just know exactly what I want when I see it. So hopefully I see it very, very soon!


Thank you everyone, you've made a difficult time actually kind of fun and exciting :D


ejwme
2010-07-14 13:10:49

way to dish out the advice, there.


ISEEWHATYOUDIDTHERE!

nice.


cburch
2010-07-14 14:45:27

nice.


Very true.


dwillen
2010-07-14 14:57:11

took me a minute


chefjohn
2010-07-19 02:17:53

and another ic wut u did there to the thread title/topic!


hiddenvariable
2010-07-19 02:21:12
